Mitsubishi Diamana BB Blueboard Wood Shaft
Mitsubishi Diamana BB Blueboard Wood Shaft
Couldn't load pickup availability
Comes Assembled With Free Adapter & Grip! Please note that there are no returns on all custom-built shafts.
For further customization please get in touch with our friendly staff, at sales@niceongolf.com.au.
Diamana™ BB Overview
Diamana™ BB (Blue Board) – the second profile in the most recent generation – is designed with all the traditional branding that made Diamana™ so beloved – including a return to the original 53/63/73/83 weight class designations – and all the engineering prowess and material innovation that made the brand dominant on tour.
To deliver maximum increased energy transfer, Super high-modulus 80-Ton Dialead Pitch Fiber is used in the butt section. To lower torque and provide greater stability, high modulus 46 ton fiber is used in the shaft’s angle plies. And, to retain Diamana’s ‘unlike any other’ feel, Mitsubishi has incorporated their proprietary Xlink Tech™ Resin System to increase overall strength and durability of the shaft while also driving carbon fiber volume up for better feel.
Key Features Include:
- 80-ton DIALEAD Pitch Fiber in butt section to maximize stability and energy transfer
- High modulus 46-ton fiber in angle plies to lower torque without increasing weight
- Xlink Tech™ Resin System to increases the strength and durability of the shaft
Who should play it? Golfers in search of a modern, pro-grade shaft with an incredible smooth feel and premium performance characteristics.
Fit Guide
| DRIVER MPH/YDS | <80/210 | 81-90/210-239 | 91-105/240-259 | >106/260 |
|---|---|---|---|---|
| R2/R | R/SR | S/X | ||
| R | R/SR | S/X | X/TX | |
| R | R/SR/S | S/X | X/TX | |
| S/X | X/TX | |||
| S/X | TX |
IMPORTANT: For reference only. Mitsubishi Golf recommends being fit by a professional fitter.
Diamana™ BB Specifications
| Shaft | Flex | Length | Weight/GMS | Tip OD | Tip Length | Butt OD | Torque | Kick Point |
|---|---|---|---|---|---|---|---|---|
| Diamana™ BB 43 | R2 | 46 | 44 | 0.335 | 3 | 0.596 | 5.1 | MID-HIGH |
| Diamana™ BB 43 | R | 46 | 45 | 0.335 | 3 | 0.598 | 5.1 | MID-HIGH |
| Diamana™ BB 43 | SR | 46 | 47 | 0.335 | 3 | 0.600 | 5.1 | MID-HIGH |
| Diamana™ BB 43 | S | 46 | 48 | 0.335 | 3 | 0.602 | 5.1 | MID-HIGH |
| Diamana™ BB 43 | X | 46 | 49 | 0.335 | 3 | 0.606 | 5.1 | MID-HIGH |
| Diamana™ BB 53 | R | 46 | 50 | 0.335 | 3 | 0.596 | 4.9 | MID-HIGH |
| Diamana™ BB 53 | SR | 46 | 52 | 0.335 | 3 | 0.596 | 4.9 | MID-HIGH |
| Diamana™ BB 53 | S | 46 | 54 | 0.335 | 3 | 0.598 | 4.9 | MID-HIGH |
| Diamana™ BB 53 | X | 46 | 55 | 0.335 | 3 | 0.600 | 4.9 | MID-HIGH |
| Diamana™ BB 53 | TX | 46 | 56 | 0.335 | 3 | 0.600 | 4.9 | MID-HIGH |
| Diamana™ BB 63 | R | 46 | 60 | 0.335 | 3 | 0.602 | 3.2 | MID-HIGH |
| Diamana™ BB 63 | SR | 46 | 61 | 0.335 | 3 | 0.602 | 3.2 | MID-HIGH |
| Diamana™ BB 63 | S | 46 | 61 | 0.335 | 3 | 0.602 | 3.2 | MID-HIGH |
| Diamana™ BB 63 | X | 46 | 62 | 0.335 | 3 | 0.602 | 3.2 | MID-HIGH |
| Diamana™ BB 63 | TX | 46 | 62 | 0.335 | 3 | 0.602 | 3.1 | MID-HIGH |
| Diamana™ BB 73 | S | 46 | 70 | 0.335 | 3 | 0.602 | 2.9 | MID-HIGH |
| Diamana™ BB 73 | X | 46 | 71 | 0.335 | 3 | 0.604 | 2.9 | MID-HIGH |
| Diamana™ BB 73 | TX | 46 | 72 | 0.335 | 3 | 0.604 | 2.9 | MID-HIGH |
| Diamana™ BB 83 | S | 46 | 80 | 0.335 | 3 | 0.604 | 2.8 | MID-HIGH |
| Diamana™ BB 83 | X | 46 | 81 | 0.335 | 3 | 0.604 | 2.8 | MID-HIGH |
| Diamana™ BB 83 | TX | 46 | 81 | 0.335 | 3 | 0.604 | 2.8 | MID-HIGH |
